☞ Before starting to work, the instrument has to become acclimatised to the ambient temperature. Take at least 15 minutes into account or approximately 2 minutes per °C of temperature difference from storage to working environment.
☞ Even after adjustment of the ATR, the crosshairs may not be positioned exactly on the centre of the prism after an ATR measurement has been completed. This outcome is a normal effect. To speed up the ATR measurement, the telescope is normally not positioned exactly on the centre of the prism.
These small deviations ATR offsets, are calculated individually for each measurement and corrected electronically. This means that the horizontal and vertical angles are corrected twice: first by the determined ATR errors for Hz and V, and then by the individual small deviations of the current aiming.
Next step
• Adjusting a combination of instrument errors
Refer to "5.3 Combined Adjustment (l, t, i, c and ATR)".
• Adjusting the circular level
Refer to "5.4 Adjusting the Circular Level of the Instrument and Tribrach".
• Adjusting the laser/optical plummet
Refer to "5.6 Inspecting the Laser Plummet of the Instrument".
• Adjusting the tripod
Refer to "5.7 Servicing the Tripod".
